Remove the clamp that secures the wiring to the spring support bracket.
Using a pair of pliers, remove the clamps that secure the wiring to the power
board assembly container (indicated by the arrows).
Position the board assembly as shown in the figure.
Remove the connectors and the faston that connects the earth
(beware as it is fitted with an anti-sliding stop).
Remember to use the anti-sliding kit.
Unhook the three hooks that join the two casings on one side
and on the other.
Lift the lid.
