Loosen the screws which secure the control crosspiece to the cabinet.
Loosen the screws which secure the front panel to the control crosspiece.
Remove the clamp that secures the wiring.
Remove the crosspiece.
Disconnect the connector.
Using a small cross-head screwdriver, loosen the screws (shown
by the arrows) securing the control panel to the front panel.
Release the hooks that secure the control panel to the front panel, which are
situated beside the screw seats (except for the screws beside the detergent
dispenser).
