Technical Support - MDM
78/104
599 77 39-16 Rev. 00
After releasing it from the latch which secured it to the protection.
Move it in the direction shown by the dotted arrow and turn it in order
to remove it.
Safety device.
To reassemble the door safety interlock, repeat the same tasks in
reverse order.
After inserting the door device in its seat, make sure the flange is
positioned properly on the outside as shown by the arrows.
