EMC-PARTNER TRA3000 S - Page 14

TRANSIENT3000
14/162
EXT-TRA3000 S (Surge)
Installing instruction of EXT-
TRA3000 S can be found in the
Instruction Sheet (IS), delivered
with the EXT-TRA3000 S.
EXT-TRA3000 D (DIPS)
Installing instruction of EXT-
TRA3000 D can be found in the
Instruction Sheet (IS), delivered
with the EXT-TRA3000 D.
When no EXT-TRA3000 V is
installed in the TRA3000
together with the EXT-
TRA3000 D, than the black
MC bridge must be inserted
on the rear panel on PWR2
between L and PE.
