TRANSIENT3000
15/162
EXT-TRA3000 V (Variation)
Installing instruction of EXT-
TRA3000 V can be found in the
Instruction Sheet (IS), delivered
with the EXT-TRA3000 V.
EXT-TRA3000 C (Common Mode Disturbance)
Installing instruction of EXT-
TRA3000 C can be found in the
Instruction Sheet (IS), delivered
with the EXT-TRA3000 C.
Each EXT-TRA3000 is delivered with a calibration report.
The TRA3000 F-S-D-V contains a single-phase coupling / de-coupling network, which allows a controlled
superposition of the transients onto a power supply line.
All transients are generated at the same EUT power output, therefore a true single port test is possible. The
TRA3000 F-S-D-V-C allows the automated switching of coupling paths and the programming of a large
range of test sequences.
The tester TRA3000 F-S-D-V-C is a stand-alone equipment for automated EMC test without a PC.
