36 DCM00044 REV. 14
4.3 Take Inventory of Small Parts
4.3.1 Cables
Three cables connect the power supply and actuator: the analog data cable, the control
cable, and the RF cable. If the system is to be automated, you may also need a remote
start cable. Check your invoice for cable types and cable lengths.
Table 4.1 Standard small parts included with Power Supply and/or Actuator
Part or Kit Description Qty Comments
11008-09-001 HANDLE, EXTENSION 1
Toolkit M1A50A19
11008-09-002 SOCKET, 5/8” MODIFIED 1
X3A50325 SPACER, 6MM 1
101-118-039 WRENCH SPANNER #0472 1
211-099 PASTE, MOLYKOTE GN METAL 2.8 OZ 1
211-205 EMORY, 600 GRIT(SHEET) 00346007 1
211-206 PAD, METAL FINISH 41028416 MSC 1
211-636 CANVAS BAG W/BRANSON LOGO 1
211-658 SET, ALLEN, 1.5-5MM, HEX:05051628 1
211-659 WRENCH HEX ALLEN, 6MM, 88350137 1
211-660 WRENCH HEX, 8MM,05051925 MSC 1
48000-03-011 WRENCH, SPANNER 1
M1A50A42 SHIM, .001 1
M1A50A45 SPACER, 1MM MSC 81757700 1
M1A00117 SINGLE PALM BUTTON W/E-STOP N/A
Optional
M1A00137 FOOTSWITCH ASSEMBLY N/A
M1A00A10 DUAL PALM BUTTON ULTRAWELD 20 N/A
M1A00A11 OPTO-TOUCH START SWITCH ASSY N/A
211-968 Wrench, 1-3/8 Open End, 1/2 Dr N/A
Table 4.2 List of Cables
EDP number Description Comments
101-266-8R CABLE, ANALOG DATA EN Compliant Part
101-640-8 CABLE, CONTROL EN Compliant Part
101-240-177 CBL EXT 15' RF SHLD J931CS CE
EN Compliant when used
with Converter 101-135-065
J1A00230 CABLE,AUTOMATION INTERFACE,10'
