4.2 Handling and Unpacking
If there are any visible signs of damage to the shipping containers or the product, or you
later discover hidden damage, take pictures, and NOTIFY YOUR CARRIER IMMEDIATELY.
Save the packing material.
1. Unpack the Ultraweld L20 components as soon as they arrive. Refer to the following procedures.
2. Verify you have all of the equipment ordered. Some components are packed inside other boxes.
3. Inspect the controls, indicators, and surfaces for signs of damage.
4. Save all packing material. Evaluation systems will be returned using this material.
4.2.1 Unpack the Power Supply
Power supplies are shipped in a cardboard carton. Power supplies weight approximately 36
lbs (16 kg).
1. Open the box, remove foam top packing half and lift the power supply out.
2. Remove the toolkit(s) and other components shipped with the power supply. These items may be
shipped in small, separate boxes, or underneath the power supply in the box.
3. Save the packing material; evaluation systems will be returned using this packing material.
4.2.2 Unpack the Ultraweld L20 Actuator
The actuator is assembled and ready to install. L20 Actuators weight approximately 97 lbs
(44 kg).
Move the shipping container close to the intended installation location, leave it on the
floor.
1. Open the top of the cardboard box, remove the insert from the top of the box and set it aside.
2. The toolkit, mounting bolts, and converter and/or booster are shipped with the actuator but in
separate shipping box(es). Unpack the converter, booster, toolkit and bolts from their packages.
3. Save the packing material.
CAUTION Heavy Object
Equipment exceeds 40 lb. Sling required to lift.
