44 DCM00002 REV. 16
WELDMODE
To select the determining criteria for cut off of the ultrasonic energy. See 5.5 Weld Mode
Screen.
COUNTER
To reset the batch counter.
ADVANCED
To enter selections pertaining to afterburst, squeeze and hold time. See 5.6 Advanced
Weld Settings Screen.
EXIT
To return to Menu Options. See 5.3 Menu Options Screen.
