DCM00002 REV. 16 81
• From the PC HyperTerminal go to Transfer, Capture Text
• It is recommended that the data be stored on a floppy disk in the A: drive. A file name
a:\tsdata.txt or similar can be used. Use a .txt extension
• From the touchscreen controller press COM DATA. When the next screen appears press PRESETS
or SEQUENCE to upload the data to the PC HyperTerminal
• When all data has been sent to the PC go back to Transfer, Capture Text and Stop. This will close
the file with data stored
Upload Procedure:
The captured text file contains all the information required to return the data back to any
waiting touchscreen controller. Assuming the HyperTerminal setup was saved, load that
setup to start the system. If you have not saved the setup you can use the above steps to
setup a new HyperTerminal session.
Controller to Controller
The PC is required only to store the data. If desired, two touchscreen controllers can be
attached via the Null Modem cable and the data sent directly from one controller to
another. The BAUD rate must be identical, there is no other setup.
NOTICE
Leave the controller at the RUN screen. From the PC, use the Send
Text File (instead of Capture Text) to upload the file to the controller.
