Emerson Vilter MicroVission - Multi-IO Board Analog Input Jumper Tables

2 – 5
Section 2 • Hardware Architecture
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Channel 9 Signal JP - 33 JP - 34 JP - 35 JP - 36
Analog
Input 9
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 10 Signal JP - 37 JP - 38 JP - 39 JP - 40
Analog
Input 10
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Table 2-3. Multi-IO Board Analog Input Jumper Tables
Channel 1 Signal JP - 1 JP - 2 JP - 3 JP - 4
Analog
Input 1
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 2 Signal JP - 5 JP - 6 JP - 7 JP - 8
Analog
Input 2
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 3 Signal JP - 9 JP - 10 JP - 11 JP - 12
Analog
Input 3
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 4 Signal JP - 13 JP - 14 JP - 15 JP - 16
Analog
Input 4
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 5 Signal JP - 17 JP - 18 JP - 19 JP - 20
Analog
Input 5
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 6 Signal JP - 21 JP - 22 JP - 23 JP - 24
Analog
Input 6
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 7 Signal JP - 25 JP - 26 JP - 27 JP - 28
Analog
Input 7
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Channel 8 Signal JP - 29 JP - 30 JP - 31 JP - 32
Analog
Input 8
0-5 VDC OUT OUT OUT OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
0-10 VOLT OUT OUT IN OUT
RTD OUT OUT OUT IN
Multi-IO Board Analog Input Jumper Tables
The following tables are used to congure each chan-
nel of the Multi-IO board analog inputs, signal type and
range desired by the operator, see Table 2-3.
