22 – 3

Section 22 • Parts

MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3

Item No. Description VPN

1 STANDOFF #6X6/32X3/4” STEEL METAL HEX 3485SP

2 SCREW 6-32NCX3/8 MACHINE RD HD GALV 2078B

3 (OPTIONAL) - DIGITAL INPUT / OUTPUT BOARD 3485D4

4 (OPTIONAL) - ANALOG INPUT BOARD - 8 INPUT 3485A8

5.1 MULTI I/O BOARD 3669MIO

5.2 240VAC VERSION OF MULTI I/O BOARD 3669MIO-240V

6 24VDC POWER SUPPLY -100 WATT 3669KPS

7 FUSE 2A 3669F

8.1 RELAY 2 POLE 120VAC 3669Z

8.2 RELAY 2 POLE 240VAC 3669Z-240V

9.1 SOCKET RELAY 2 POLE 120VAC 3669ZS

9.2 240V - SOCKET RELAY 2 POLE 240VAC 3669ZS-240V

10 TERMINAL BLOCK CDU 2.5 DECA DIN 3485TB

11 EMI FILTER 3485EMF

12 FERRITE BEAD CORE 3485FBC

13 EMERGENCY STOP SWITCH 3485H

MicroVission - Main Enclosure Electrical Components
