Section 6 • Alarms and Trips
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Warnings Inhibits Alarms Trips
Not Running (Idle) Pre-Start Running Running
Digital Aux In 1:
Below messages will be displayed when Digital Aux In 1 satisfy safety conditions.
Warnings are displayed in IDLE condition and it is monitored under Inhibit Checkbox (Refer Figure 6-4).
When “None” is selected in Trips/Alarm then No Alarm and Trip for Digital Aux In 1 is monitored, Similarly When
“None” is selected in Inhibit then No Warning and Inhibit for Digital Aux In 1 is monitored.
Digital Aux In 1 Warning Digital Aux In 1 Inhibit Digital Aux In 1 Alarm Digital Aux In 1 Trip
Inhibit Checked and
“Start Inhibit if ON” and
Digital Aux In 1 is HIGH
Inhibit Checked and
“Start Inhibit if OFF” and
Digital Aux In 1 is LOW
Inhibit Checked and “Start Inhibit
if ON” and Digital Aux In 1 is
HIGH
Inhibit Checked and “Start Inhibit
if OFF” and Digital Aux In 1 is
LOW
Trip/Alarm Checked
and “Alarm if ON” and
Digital Aux In 1 is HIGH
Trip/Alarm Checked
and “Alarm if OFF” and
Digital Aux In 1 is LOW
Trip/Alarm Checked and
“Trip if ON” and Digital
Aux In 1 is HIGH
Trip/Alarm Checked and
“Trip if OFF” and Digital
Aux In 1 is LOW
Digital Aux In 2:
Below messages will be displayed when Digital Aux In 2 satisfy safety conditions.
Warnings are displayed in IDLE condition and it is monitored under Inhibit Checkbox (Refer Figure 6-4).
When “None” is selected in Trips/Alarm then No Alarm and Trip for Digital Aux In 2 is monitored, Similarly When
“None” is selected in Inhibit then No Warning and Inhibit for Digital Aux In 2 is monitored.
Digital Aux In 2 Warning Digital Aux In 2 Inhibit Digital Aux In 2 Alarm Digital Aux In 2 Trip
Inhibit Checked and
“Start Inhibit if ON” and
Digital Aux In 2 is HIGH
Inhibit Checked and
“Start Inhibit if OFF” and
Digital Aux In 2 is LOW
Inhibit Checked and “Start Inhibit
if ON” and Digital Aux In 2 is
HIGH
Inhibit Checked and “Start Inhibit
if OFF” and Digital Aux In 2 is
LOW
Trip/Alarm Checked
and “Alarm if ON” and
Digital Aux In 2 is HIGH
Trip/Alarm Checked
and “Alarm if OFF” and
Digital Aux In 2 is LOW
Trip/Alarm Checked and
“Trip if ON” and Digital
Aux In 2 is HIGH
Trip/Alarm Checked and
“Trip if OFF” and Digital
Aux In 2 is LOW
