Emerson Vilter MicroVission - Low Oil Filter in Pressure; Low Oil Filter out Pressure; Low Discharge 2 Pressure; Low Discharge #2 Temperature

6 – 12
Section 6 • Alarms and Trips
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Warnings Inhibits Alarms Trips
Not Running (Idle) Pre-Start Running Running
Low Oil Filter In Pressure:
Below Messages will be displayed on Main Screen when there is a failure while reading Filter Inlet Pressure value from
Measuring Instrument. There is no user congured setpoint.
Low Oil Filter In Pressure
Warning
Low Oil Filter In Pressure Inhibit
Low Oil Filter In Pressure
Trip
Filter Inlet Pressure <=
-66.5 Psig
Filter Inlet Pressure <= -66.5 Psig
Filter Inlet Pressure <=
-66.5 Psig
Low Oil Filter Out Pressure:
Below Messages will be displayed on Main Screen when there is a failure while reading Filter Outlet Pressure value
from Measuring Instrument. There is no user congured setpoint.
Low Oil Filter Out
Pressure Warning
Low Oil Filter Out Pressure Inhibit
Low Oil Filter Out
Pressure Trip
Filter Outlet Pressure <=
-66.5 Psig
Filter Outlet Pressure <= -66.5
Psig
Filter Outlet Pressure <=
-66.5 Psig
Low Discharge #2 Pressure:
Below Messages will be displayed on Main Screen when there is a failure while reading Discharge 2 Pressure value
from Measuring Instrument. There is no user congured setpoint.
These safeties will be only active when No. of Cylinders set in Conguration screen is “12 cyl” or “16 cyl”.
Low Discharge 2 Pressure
Warning
Low Discharge 2 Pressure Inhibit
Low Discharge 2 Pressure
Trip
Discharge 2 Pressure <=
-66.5 Psig
Discharge 2 Pressure <= -66.5
Psig
Discharge 2 Pressure <=
-66.5 Psig
Low Discharge #2 Temperature:
Below Messages will be displayed on Main Screen when there is a failure while reading Discharge 2 Temperature
value from Measuring Instrument. There is no user congured setpoint.
These safeties will be only active when No. of Cylinders set in Conguration screen is “12 cyl” or “16 cyl”.
Low Discharge 2
Temperature Warning
Low Discharge 2 Temperature
Inhibit
Low Discharge 2
Temperature Trip
Discharge 2 Temperature
<= -100 °F
Discharge 2 Temperature <=
-100 °F
Discharge 2 Temperature
<= -100 °F
