Section 6 • Alarms and Trips
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Warnings Inhibits Alarms Trips
Not Running (Idle) Pre-Start Running Running
Digital Aux In 3:
Below messages will be displayed when Digital Aux In 3 satisfy safety conditions.
Warnings are displayed in IDLE condition and it is monitored under Inhibit Checkbox (Refer Figure 6-4).
When “None” is selected in Trips/Alarm then No Alarm and Trip for Digital Aux In 3 is monitored, Similarly When
“None” is selected in Inhibit then No Warning and Inhibit for Digital Aux In 3 is monitored.
Digital Aux In 3 Warning Digital Aux In 3 Inhibit Digital Aux In 3 Alarm Digital Aux In 3 Trip
Inhibit Checked and
“Start Inhibit if ON” and
Digital Aux In 3 is HIGH
Inhibit Checked and
“Start Inhibit if OFF” and
Digital Aux In 3 is LOW
Inhibit Checked and “Start Inhibit
if ON” and Digital Aux In 3 is
HIGH
Inhibit Checked and “Start Inhibit
if OFF” and Digital Aux In 3 is
LOW
Trip/Alarm Checked
and “Alarm if ON” and
Digital Aux In 3 is HIGH
Trip/Alarm Checked
and “Alarm if OFF” and
Digital Aux In 3 is LOW
Trip/Alarm Checked and
“Trip if ON” and Digital
Aux In 3 is HIGH
Trip/Alarm Checked and
“Trip if OFF” and Digital
Aux In 3 is LOW
Digital Aux In 4:
Below messages will be displayed when Digital Aux In 4 satisfy safety conditions.
Warnings are displayed in IDLE condition and it is monitored under Inhibit Checkbox (Refer Figure 6-4)
When “None” is selected in Trips/Alarm then No Alarm and Trip for Digital Aux In 4 is monitored, Similarly When
“None” is selected in Inhibit then No Warning and Inhibit for Digital Aux In 4 is monitored.
Digital Aux In 4 Warning Digital Aux In 4 Inhibit Digital Aux In 4 Alarm Digital Aux In 4 Trip
Inhibit Checked and
“Start Inhibit if ON” and
Digital Aux In 4 is HIGH
Inhibit Checked and
“Start Inhibit if OFF” and
Digital Aux In 4 is LOW
Inhibit Checked and “Start Inhibit
if ON” and Digital Aux In 4 is
HIGH
Inhibit Checked and “Start Inhibit
if OFF” and Digital Aux In 4 is
LOW
Trip/Alarm Checked
and “Alarm if ON” and
Digital Aux In 4 is HIGH
Trip/Alarm Checked
and “Alarm if OFF” and
Digital Aux In 4 is LOW
Trip/Alarm Checked and
“Trip if ON” and Digital
Aux In 4 is HIGH
Trip/Alarm Checked and
“Trip if OFF” and Digital
Aux In 4 is LOW
