Section 6 • Alarms and Trips
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Warnings Inhibits Alarms Trips
Not Running (Idle) Pre-Start Running Running
Low Oil Pressure Diff.:
Below Messages will be displayed on Main Screen when Oil Pressure Diff. value drops below congured setpoints.
Refer Figure 6-3 for Alarm & Trip setpoints.
These safeties will be only active once Oil Pressure Bypass Timer is lapsed.
Oil Pressure Calculation is as follows: Oil Pressure = Oil Manifold Pressure – Suction Pressure
Low Oil Pressure Diff
Alarm
Low Oil Pressure Diff Trip
Oil Pressure Diff. <=
Low Oil Pressure Diff.
Alarm Setpoint
Oil Pressure Diff. <= Low
Oil Pressure Diff. Trip
Setpoint
High Filter Diff. Pressure - Start:
Below Messages will be displayed on Main screen when Filter Diff. Pressure value rises above congured setpoints.
Refer Figure 6- 3 for Alarm & Trip setpoints.
These safeties will be only active if below two conditions are met:
1) When Oil Monitoring option selected in Conguration Screen is “Oil Filter In & Oil Filter Out” or “Only Oil Filter In”.
2) When Filter Diff. Pressure Changeover Timer is running.
Filter Diff. Pressure Calculation for Oil Monitoring options, “Oil Filter In & Oil Filter Out” & “Only Oil Filter In” will be
respectively as below:
a) Filter Diff. Pressure = Oil Filter Inlet Pressure – Oil Filter Outlet Pressure.
b) Filter Diff. Pressure = Oil Filter Inlet Pressure – Oil Manifold Pressure.
High Filter Diff Pressure
Start Warning
High Filter Diff Pressure Start
Inhibit
High Filter Diff Pressure
Alarm
High Filter Diff Pressure
Trip
Filter Diff. Pressure >=
High Filter Diff. Pressure
– Start Alarm Setpoint
Filter Diff. Pressure >= High
Filter Diff. Pressure – Start Alarm
Setpoint
Filter Diff. Pressure
>= High Filter Diff.
Pressure – Start Alarm
Setpoint
Filter Diff. Pressure >=
High Filter Diff. Pressure
– Start Trip Setpoint
