Emerson Vilter MicroVission - Analog Input Board Jumper Tables

2 – 10
Section 2 • Hardware Architecture
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Analog Input Board Jumper Tables
The following tables are used to congure each channel
of the analog input board signal type and range desired
by the operator, see Table 2-6.
Table 2-6. Analog Input Board Jumper Tables
Channel 1 Signal JP - 1 JP - 2 JP - 3 JP - 27 JP - 35
Analog
Input 1-A*
0-5 AMP OUT OUT OUT OUT IN
Analog
input 1-B**
0-5 VOLT OUT OUT OUT OUT OUT
1-5 VOLT OUT OUT OUT OUT OUT
0-10 VOLT OUT OUT IN OUT OUT
4-20 mA IN OUT OUT OUT OUT
ICTD OUT IN OUT OUT OUT
RTD OUT OUT OUT IN OUT
* Use Analog Input 1-A when 0-5 AMP
secondary current transformers are
installed in the motor starter.
** Use Analog Input 1-B when current
transformers are installed in the motor
starter.
Channel 2 Signal JP - 4 JP - 5 JP - 6 JP - 28
Analog
Input 2
0-5 VOLT OUT OUT OUT OUT
1-5 VOLT OUT OUT OUT OUT
0-10 VOLT OUT OUT IN OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
RTD OUT OUT OUT IN
Channel 3 Signal JP - 7 JP - 8 JP - 9 JP - 29
Analog
Input 3
0-5 VOLT OUT OUT OUT OUT
1-5 VOLT OUT OUT OUT OUT
0-10 VOLT OUT OUT IN OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
RTD OUT OUT OUT IN
Channel 4 Signal JP - 10 JP - 11 JP - 12 JP - 30
Analog
Input 4
0-5 VOLT OUT OUT OUT OUT
1-5 VOLT OUT OUT OUT OUT
0-10 VOLT OUT OUT IN OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
RTD OUT OUT OUT IN
Channel 5 Signal JP - 13 JP - 14 JP - 15 JP - 31
Analog
Input 5
0-5 VOLT OUT OUT OUT OUT
1-5 VOLT OUT OUT OUT OUT
0-10 VOLT OUT OUT IN OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
RTD OUT OUT OUT IN
