Channel 6 Signal JP - 16 JP - 17 JP - 18 JP - 32
Analog
Input 6
0-5 VOLT OUT OUT OUT OUT
1-5 VOLT OUT OUT OUT OUT
0-10 VOLT OUT OUT IN OUT
4-20 mA IN OUT OUT OUT
ICTD OUT IN OUT OUT
RTD OUT OUT OUT IN
Table 2-6. Analog Input Board Jumper Tables (continued)
Channel 7 Signal JP - 19 JP - 20 JP - 21 JP - 33 JP – 25*
Analog
Input 7
0-5 VOLT OUT OUT OUT OUT 2
1-5 VOLT OUT OUT OUT OUT 2
0-10 VOLT OUT OUT IN OUT 2
4-20 mA IN OUT OUT OUT 2
ICTD OUT IN OUT OUT 2
RTD OUT OUT OUT IN 2
ACTUATOR OUT OUT OUT OUT 1
POTENTIOMETER OUT OUT OUT OUT 3
*JP-25
• Position 1 = sends +24VDC
(unregulated) to “supply”
terminal (2.2A limit)
• Position 2 = sends +24VDC
(regulated) to “supply”
terminal (25mA limit)
• Position 3 = sends +5VDC
(regulated) to “supply”
terminal
Channel 8 Signal JP - 22 JP - 23 JP - 24 JP - 34 JP – 26*
Analog
Input 8
0-5 VOLT OUT OUT OUT OUT 2
1-5 VOLT OUT OUT OUT OUT 2
0-10 VOLT OUT OUT IN OUT 2
4-20 mA IN OUT OUT OUT 2
ICTD OUT IN OUT OUT 2
RTD OUT OUT OUT IN 2
ACTUATOR OUT OUT OUT OUT 1
POTENTIOMETER OUT OUT OUT OUT 3
*JP-26
• Position 1 = sends +24VDC
(unregulated) to “supply”
terminal (2.2A limit)
• Position 2 = sends +24VDC
(regulated) to “supply”
terminal (25mA limit)
• Position 3 = sends +5VDC
(regulated) to “supply”
terminal
