4 – 2
Section 4 • Menu Screen
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Conguration
Navigates to Conguration screen where the operator
can congure all the initial system parameters.
Data Backup
Navigates to the Data Backup screen where the opera-
tor can back up setpoints, conguration parameters and
calibration settings to a USB memory device. In addition,
this allows the restoration of previously saved database
les.
Compressor Sequencing
Navigates to the Compressor Sequencing screen where
the operator can set-up compressor to sequence up to
nine other compressors. This option will be only avail-
able when Compressor Sequencing option is enabled
from Conguration Screen Page 3.
Auxiliary IO
Navigates to the Auxiliary IO screen where the operator
can set-up 4 Auxiliary Digital Inputs, 4 Auxiliary Digital
Outputs, 8 Auxiliary Analog Inputs and 5 Auxiliary
Analog Outputs. Auxiliary IO option is enabled from
Conguration Screen When any of the auxiliary is
enabled.
Condenser Control
Navigates to the Condenser Control screen where the
operator can set-up Condenser Control Run Mode,
Setpoints, Condenser VFD, Condenser Step Control
and Prole. This option will be only available when
Condenser Control option is enabled from Conguration
Screen Page 2.
Main
Navigates back to the Main screen.
