5 – 8
Section 5 • Compressor Control
MicroVission Controller • Operation and Service Manual • Emerson • 35391MV 1.3
Pulldown Start Temperature: If Pulldown Operation
is running, then the Auto Cycle functionality will use
Pulldown Start Temperature (Shown in Figure 5-7)
instead of Setpoint 1 Start Temperature to start the
compressor on Auto Cycle.
Pulldown Stop Temperature: If Pulldown Operation
is running, then the Auto Cycle functionality will use
Pulldown Stop Temperature (Shown in Figure 5-7) in-
stead of Setpoint 1 Stop Temperature to stop the com-
pressor on Auto Cycle.
Figure 5-7. Compressor Control Screen – Auto Cycle (Process Temperature) with Pulldown
Running
