multi N/C 2100S First commissioning
41
4 First commissioning
4.1 Site requirements
4.1.1 Installation conditions
The following requirements are placed on the climatic conditions in the operating room
of the analyzer:
Temperature range: +10 °C to +35 °C
max. humidity: 90 % at 30 °C
Air pressure: 0.7 bar to 1.06 bar
The laboratory atmosphere should be as low as possible in TOC, nitrogen oxide and dust
and free of draught, corrosive vapors and vibration. Smoking is prohibited in the
operating room of the analyzer!
The following requirements are placed on the location of the analyzer:
Do not locate the analyzer directly near a door or window.
Place the analyzer on a heat-resistant and acid-resistant surface.
Do not locate the analyzer near sources of electromagnetic interference.
Avoid direct sunlight and radiation from heaters onto the analyzer; if necessary
ensure air-conditioning.
Never obstruct the front doors, the left side wall and the ventilation slots of the
analyzer with other equipment or furnishings!
Keep a safety distance of at least 5 cm from the back and the right side of the
equipment to other equipment or walls!
4.1.2 Space requirement
NOTICE
The external solids module or the chemiluminescence detector (CLD) must be located to
the right of the analyzer. The autosampler is mounted on the analyzer.
ayout of the other components can be adapted to the local conditions.
The space required is a function of all components needed for the measurement. Leave
adequate space for the PC, monitor, printer and any add-on equipment.
