multi N/C 2100S Maintenance and care
69
6. Undo the adjustment screw at the
NPOC needle valve.
7.
Regulate the desired NPOC purging
flow:
Increasing the NPOC purging flow
- turn needle valve to the left
Reducing the NPOC purging flow
- turn needle valve to the right
Note
:
The current NPOC purging
flow is
indicated in the multi
N/C 2100S in the
window
SYSTEM STATE after MFM2.
8.
Relock the adjustment screw at the
needle valve.
9.
Close the side wall.
Connect the grounding conductor
connection to the left side wall.
First screw the screws into the botto
m
and then the top side. Tighten the
screws in turn.
7.3 Replacing the water traps
NOTICE
The water traps (TC Pre
-filter and disposable retention filter) can be replaced in the
switched
-on state but not during a measurement. Always replace both water traps!
The water traps only serve their function if they are inserted in the order and installation
direction specified!
Replace the water traps dependent on the sample matrix, but no later than after 6
months, as follows:
