Endress+Hauser Analytik Jena multi N/C 2100S User Manual

multi N/C 2100S Connecting add-on devices
43
5 Connecting add-on devices
CAUTION
Before connecting add
-on devices switch off the analyzer. Always connect the add-on
devices to the multi N/C 2100S when it is
switched off!
5.1 Autosampler AS 60
CAUTION
Ensure that the waste hose is not squeezed.
NOTICE
Observe the user manual of the
AS 60 during installation!
Fig. 19 AS 60 mounted on the analyzer multi N/C 2100S
Connect the sampler to the analyzer as follows:
1. Place the sampler on the analyzer.
2. Attach the autosampler with the Allen
screws supplied to the housing
component of the multi N/C 2100S
alternating at the intended locations by
means of an Allen key.
