multi N/C 2100S Transport and storage
103
9 Transport and storage
9.1 Transport
9.1.1 Preparing the analyzer for transport
WARNING
There is a risk of burning on the combustion furnace! Only remove the combustion
furnace when the device is cold or allow the
device to cool down sufficiently!
CAUTION
When removing the glass components there is a risk of injury from glass breakage!
Remove all glass components carefully from the analyzer!
NOTICE
Unsuitable packaging material and residue of measuring solution and chemicals can
damage individual components of the analyzer!
Only transport the analyzer in its original packaging! Ensure that the analyzer is fully
drained and all transport locks have b
een fitted!
Prepare the analyzer for transport as follows:
1. Rinse the phosphoric acid pump and corresponding hoses with ultrapure water and
then drain these components.
2. Switch off the analyzer from the main switch and allow the equipment to cool down.
3. Disconnect the gas supply and unplug the mains plug from the mains outlet.
4. Undo all connections on the back of the analyzer.
5. Open the doors of the analyzer and remove the reagent bottle and drip tray and any
other loose accessory components.
6. Pull the hoses off the connections at the halogen trap and press the halogen trap out
of the clamps.
7. Pack open hose ends in protective bags and secure them e.g. using adhesive tape.
8. Open the left side wall,
• Unscrew the four fastening screws; the screws are undetachable and remain in
the wall.
• Disconnect the grounding conductor connection and put the side wall safely
aside.
9. Remove the combustion tube (see section "Removing the combustion tube" p. 73).
10. Remove the TIC condensate container and condensation coil (see section "Removing
and cleaning the TIC condensate container and condensation coil" p. 79).
11. Remove the combustion furnace (see section "Removing the combustion furnace"
p. 83).
