Proline Promag 53 MODBUS RS485 Commissioning
Endress+Hauser 89
!
Note!
The parameters described in the table can be found in the "MODBUS RS485" group of the "BASIC
FUNCTION" block in the function matrix (see separate "Description of Device Functions" manual).
6304 PARITY Selection depends on the "TRANSMISSION MODE" function:
NONE; EVEN; ODD
• Available in the ASCII transfer mode → even or uneven parity bit
(EVEN, ODD).
• Available in the RTU transfer mode → no parity bit (NONE) or even
or uneven parity bit (EVEN, ODD).
Factory setting: EVEN
6305 BYTE ORDER For selecting the byte transmission sequence for the Integer, Float and
String data types:
0 - 1 - 2 - 3
3 - 2 - 1 - 0
2 - 3 - 0 - 1
1 - 0 - 3 - 2
Factory setting: 1 - 0 - 3 - 2
!
Note!
The transmission sequence must suit the MODBUS master.
6306 DELAY TELEGRAM REPLY For entering a delay time after which the measuring device replies to
the request telegram of the MODBUS master. This allows
communication to be adapted to slow MODBUS masters:
0 to 100 ms
Factory setting: 10 ms
Back to the HOME position:
→ Press and hold down the X key for longer than three seconds or
→ Repeatedly press and release the X key = Exit the function matrix step by step
Quick Setup "Communication"
