Proline Prowirl F 200 PROFIBUS PA Commissioning
Endress+Hauser 123
Parameter overview with brief description
Parameter Prerequisite Description Selection / User
entry
Factory setting
Assign simulation process variable – Select a process variable for
the simulation process that is
activated.
• Off
• Volume flow
• Corrected volume
flow
• Mass flow
• Flow velocity
• Temperature
• Calculated
saturated steam
pressure
*
• Steam quality
*
• Total mass flow
*
• Condensate mass
flow
*
• Energy flow
• Heat flow
difference
*
• Reynolds number
Off
Value process variable One of the following options is
selected in the Assign
simulation process variable
parameter (→  123):
• Volume flow
• Corrected volume flow
• Mass flow
• Flow velocity
• Temperature
*
• Calculated saturated steam
pressure
*
• Steam quality
*
• Total mass flow
*
• Condensate mass flow
*
• Energy flow
*
• Heat flow difference
*
• Reynolds number
*
Enter the simulation value for
the selected process variable.
Depends on the
process variable
selected
0
Frequency simulation The Frequency option is
selected in the Operating
mode parameter.
Switch the simulation of the
frequency output on and off.
• Off
• On
Off
Frequency value The On option is selected in
the Frequency simulation
parameter.
Enter the frequency value for
the simulation.
0.0 to 1 250.0 Hz 0.0 Hz
Pulse simulation The Pulse option is selected in
the Operating mode
parameter.
Set and switch off the pulse
output simulation.

For Fixed value option:
Pulse width parameter
(→  106) defines the
pulse width of the pulses
output.
• Off
• Fixed value
• Down-counting
value
Off
Pulse value In the Pulse simulation
parameter (→  123), the
Down-counting value option
is selected.
Enter the number of pulses for
simulation.
0 to 65 535 0
Switch output simulation The Switch option is selected
in the Operating mode
parameter.
Switch the simulation of the
switch output on and off.
• Off
• On
Off
Switch status The On option is selected in
the Switch output simulation
parameter (→  123).
Select the status of the status
output for the simulation.
• Open
• Closed
Open
Simulation device alarm – Switch the device alarm on and
off.
• Off
• On
Off
