Proline Prowirl F 200 PROFIBUS PA Technical data
Endress+Hauser 193
Output values
(from measuring device to
automation system)
Analog input 1 to 4
• Volume flow
• Mass flow
• Corrected volume flow
• Flow velocity
• Temperature
• Calculated saturated steam pressure
• Steam quality
• Total mass flow
• Energy flow
• Heat flow difference
• Reynolds number
• Density
• Pressure
• Specific volume
• Degree of overheating
Digital input 1 to 2
• Empty pipe detection
• Low flow cut off
• Status switch output
• Status verification
Totalizer 1 to 3
• Mass flow
• Volume flow
• Corrected volume flow
• Total mass flow
• Condensate mass flow
• Energy flow
• Heat flow difference
Input values
(from automation system to
measuring device)
Analog output
• External density
• External temperature
Digital output 1 to 2 (fixed assignment)
• Digital output 1: switch positive zero return on/off
• Digital output 2: start verification
Totalizer 1 to 3
• Totalize
• Reset and hold
• Preset and hold
• Operating mode configuration:
– Net flow total
– Forward flow total
– Reverse flow total
Supported functions • Identification & Maintenance
Simplest device identification on the part of the control system and
nameplate
• PROFIBUS upload/download
Reading and writing parameters is up to ten times faster with PROFIBUS
upload/download
• Condensed status
Simplest and self-explanatory diagnostic information by categorizing
diagnostic messages that occur
Configuration of the device
address
• DIP switches on the I/O electronics module
• Local display
• via operating tools (e.g. FieldCare)
16.5 Power supply
Terminal assignment → 32
Pin assignment, device plug → 33
