16.10 Mechanical construction
Design, dimensions
For the dimensions and installation lengths of the device, see the "Technical
Information" document, "Mechanical construction" section
Weight Compact version
Weight data:
• Including the transmitter:
– Order code for "Housing", option C: 1.8 kg (4.0 lb)
– Order code for "Housing", option B: 4.5 kg (9.9 lb)
• Excluding packaging material
Weight in SI units
All values (weight) refer to devices with EN (DIN), PN 40 flanges. Weight information in
[kg].
DN
[mm]
Weight [kg]
Order code for "Housing", option C
Aluminum, AlSi10Mg, coated
1)
Order code for "Housing", option B
Stainless steel, 1.4404 (316L)
1)
15 5.1 7.8
25 7.1 9.8
40 9.1 11.8
50 11.1 13.8
80 16.1 18.8
100 21.1 23.8
150 37.1 39.8
200 72.1 74.8
250 111.1 113.8
300 158.1 160.8
1) For high-temperature/low-temperature version: values + 0.2 kg
Weight in US units
All values (weight) refer to devices with ASME B16.5, Class 300/Sch. 40 flanges. Weight
information in [lbs].
DN
[in]
Weight [lbs]
Order code for "Housing", option C
Aluminum, AlSi10Mg, coated
1)
Order code for "Housing", option B
Stainless steel, 1.4404 (316L)
1)
½ 11.3 17.3
1 15.7 21.7
1½ 22.4 28.3
2 26.8 32.7
3 42.2 48.1
4 66.5 72.4
6 110.5 116.5
