Proline Prowirl F 200 PROFIBUS PA Technical data
Endress+Hauser 201
DN
[in]
Weight [lbs]
Order code for "Housing", option C
Aluminum, AlSi10Mg, coated
1)
Order code for "Housing", option B
Stainless steel, 1.4404 (316L)
1)
8 167.9 173.8
10 240.6 246.6
12 357.5 363.4
1) For high-temperature/low-temperature version: values + 0.4 lbs
Transmitter remote version
Wall-mount housing
Depends on the material of the wall-mount housing:
• Aluminum, AlSi10Mg, coated: 2.4 kg (5.2 lb)
• Stainless steel, 1.4404 (316L): 6.0 kg (13.2 lb)
Sensor remote version
Weight data:
• Including the connection housing:
– Aluminum, AlSi10Mg, coated: 0.8 kg (1.8 lb)
– Stainless cast steel, 1.4408 (CF3M): 2.0 kg (4.4 lb)
• Excluding the connecting cable
• Excluding packaging material
Weight in SI units
All values (weight) refer to devices with EN (DIN), PN 40 flanges. Weight information in
[kg].
DN
[mm]
Weight [kg]
Connection housing
Aluminum, AlSi10Mg, coated
1)
Connection housing
Stainless cast steel, 1.4408 (CF3M)
1)
15 4.1 5.3
25 6.1 7.3
40 8.1 9.3
50 10.1 11.3
80 15.1 16.3
100 20.1 21.3
150 36.1 37.3
200 71.1 72.3
250 110.1 111.3
300 157.1 158.3
1) For high-temperature/low-temperature version: values + 0.2 kg
