Technical data Proline Prowirl F 200 PROFIBUS PA
202 Endress+Hauser
Weight in US units
All values (weight) refer to devices with ASME B16.5, Class 300/Sch. 40 flanges. Weight
information in [lbs].
DN
[in]
Weight [lbs]
Connection housing
Aluminum, AlSi10Mg, coated
1)
Connection housing
Stainless cast steel, 1.4408 (CF3M)
1)
½ 8.9 11.7
1 13.4 16.1
1½ 20.0 22.7
2 24.4 27.2
3 39.8 42.6
4 64.1 66.8
6 108.2 110.9
8 165.5 168.3
10 238.2 241.0
12 355.1 357.8
1) For high-temperature/low-temperature version: values + 0.4 lbs
Accessories
Flow conditioner
Weight in SI units
DN
1)
[mm]
Pressure rating Weight
[kg]
15 PN 10 to 40 0.04
25 PN 10 to 40 0.1
40 PN 10 to 40 0.3
50 PN 10 to 40 0.5
80 PN 10 to 40 1.4
100 PN 10 to 40 2.4
150 PN 10/16
PN 25/40
6.3
7.8
200 PN 10
PN 16/25
PN 40
11.5
12.3
15.9
250 PN 10 to 25
PN 40
25.7
27.5
300 PN 10 to 25
PN 40
36.4
44.7
1) EN (DIN)
DN
1)
[mm]
Pressure rating Weight
[kg]
15 Class 150
Class 300
0.03
0.04
25 Class 150
Class 300
0.1
