DSG-423 ENGINE
02-21
2. Apply silicone gasket and sealant to the locations
shown.
NOTE: If not secured within 4 minutes, the sealant must
be removed and the sealing area recleaned as before.
Refer to previous CAUTION & WARNING.
3. Install a new cylinder head gasket.
4. Lubricate new cylinder head bolts with clean engine
oil.
CAUTION: Cylinder head bolts are torque-to-yield
and must not be reused. New bolts must be
installed.
5. Install cylinder head carefully.
Bolt
Head
Gasket
Block
Coolant Pipes
To Next Page
