7.1.3.7. System Power
Place the curser on “SYSTEM POWER” in MONITORING menu, press [ENT] button to move
into this menu. System power monitoring elements are set in this menu. If there is a problem with
system power, it does not perform the correct measurement and functions.
GLOBAL SETTING / GENERAL / MONITORING / SYSTEM POWER / Function
Range
OFF, ON
Default
ON
Step
~
Select whether to use System Power monitoring.
GLOBAL SETTING / GENERAL / MONITORING / SYSTEM POWER / +12V Pickup
Range
0(OFF), 0.1 ~ 10.0 V
Default
1.0 V
Step
0.1 V
Set a pickup value for +12V system power alarm.
If the error of the system power measurement value deviates more than
this setting, an alarm is generated.
GLOBAL SETTING / GENERAL / MONITORING / SYSTEM POWER / Time Delay
Range
0.01 ~ 10.00 sec
Default
1.00
Step
0.01 sec
Set delay time of +12V system power alarm.
GLOBAL SETTING / GENERAL / MONITORING / SYSTEM POWER / -12V Pickup
Range
0(OFF), 0.1 ~ 10.0 V
Default
1.0 V
Step
0.1 V
Set a pickup value for -12V system power alarm.
If the error of the system power measurement value deviates more than
this setting, an alarm is generated.
[
SYSTEM POWER
]
>Function: ON
+12V Pickup: 1.0
Time Delay: 1.00
-12V Pickup: 1.0
Time Delay: 1.00
Ref. V Pickup: OFF
Time Delay: 1.00
[OFF/ON]
[
SYSTEM POWER
]
Function: ON
>+12V Pickup: 1.0
Time Delay: 1.00
-12V Pickup: 1.0
Time Delay: 1.00
Ref. V Pickup: OFF
Time Delay: 1.00
[0(OFF),0.1~10.0V]
[
SYSTEM POWER
]
Function: ON
+12V Pickup: 1.0
>Time Delay: 1.00
-12V Pickup: 1.0
Time Delay: 1.00
Ref. V Pickup: OFF
Time Delay: 1.00
[ 0.01~10.00:0.01 s]
[
SYSTEM POWER
]
Function: ON
+12V Pickup: 1.0
Time Delay: 1.00
>-12V Pickup: 1.0
Time Delay: 1.00
Ref. V Pickup: OFF
Time Delay: 1.00
[0(OFF),0.1~10.0V]
