2) Other Setup
GROUP # / FAULT INDICTION / INRUSH RESTRAINT / INRUSH DURATION T / OTHERS / Make Use ‘I’
Range
NO, YES
Default
NO
Step
~
Set whether or not to use current as decision condition for operating
function.
 When it sets to NO, the inrush current restraint interval becomes
active the switch is closed (52A) and live line status.
 When it set to YES, when the current increases above 2A, the
inrush current restraint interval is active.
8.1.5. FI Auto Reset
ETMFC610 has a function to automatically reset fault indicator target (front panel lamp y
communication BI points, etc.) after detecting fault current and when line is restored normally. The
configuration as like below;
GROUP # / FAULT INDICTION / FI Auto Reset / Reset Mode
Range
OFF/TEMP/PERM/ALL
Default
OFF
Step
~
It configures if FI Auto Reset will be used or no.
 OFF : FI Auto Reset is not used.
 TEMP : Auto Reset is applied when Temporary fault is detected on
‘IV’ FI Type.
 PERM : Auto Reset is applied when Permanent fault is detected
on ‘IV’ FI Type.
 ALL : Auto Reset is applied when all the types of fault current are
detected on ‘IV’ FI Type and ‘I’ FI Type.
GROUP # / FAULT INDICTION / FI Auto Reset / Reset Time
Range
0.01~600.00:0.01s
Default
10.00
Step
0.01s
Reset time is applied about FI Auto Reset.
After voltage comes back to live line, when the setting value is
maintained during setting time, FI will be reset automatically.
[
OTHERS
]
>Make Use ‘I’: NO
[NO/YES]
[
FI AUTO RESET
]
>Reset Mode: OFF
ResetTime: 10.00
[OFF/TEMP/PERM/ALL]
[
FI AUTO
RESET
]
>Reset Mode: OFF
>Reset Time: 10.00
[0.01~600.00:0.01s]
