6. USER INTERFACE PANEL
This section describes User Interface Panel based on the front-panel.
User Interface Panel has a LCD (20

8), keypads and LEDs to monitor selected functions and to
indicate selected function and operation status as below.
 Directly control the switch(or CB)
 Verify control status
 View system status
 View metering value
 View information stored in ETMFC610 unit
 View and change ETMFC610 settings
Figure 6-1. User Interface Panel
