10.6. Mechanism Scale

Move to “MAINTENANCE / MECHANISM SCALE” to confirm CT and VT mechanism

calibration scale. When replacing the ETMFC610 controller, the manufacturer shall notify the

manufacturer of the mechanism calibration scale indicated on the ETMFC610 before replacement.

MAINTENACE / MECHANISM SCALE

VA, VB, VC, VR, VS, VT

The mechanism calibration scale of each phase VT is displayed.

IA, IB, IC, IG, IS

The mechanism calibration scale of CT and ZCT of each phase is

displayed.

[MECHANISM SCALE]

VA:1.0000 IA:1.0000

VB:1.0000 IB:1.0000

VC:1.0000 IC:1.0000

VR:1.0000 IG:1.0000

VS:1.0000 IS:1.0000

VT:1.0000
