2.7. Cold Load Pickup
Cold Load Pickup
Function ..................................................................... DISALBE/ENABLE
Make Use ‘I’……………………………………….NO/YES
Multiple of Cold Load….………………………….1.0 to 5.0 xMTC in steps of 0.1 xMTC
Cold Load Interval Time ........................................... 1 to 720 min in steps 1 min
Pickup Level Accuracy .............................................. 5%
Timing Accuracy ....................................................... 5% of setting time or ± 20㎳
2.8. Loop Control
Loop Control
Function ..................................................................... DISABLE/ENABLE
Type Select ................................................................ NONE/SEC/TIE
Auto Sectionalizer Operation Count ......................... 1 ~ 5 Shot in steps of 1 Shot
Auto Sectionalizer Operation Time Delay ................ 0.00 to 600.00sec in steps of 0.01sec
Auto Sectionalizer Reset Time Delay ....................... 1.00 to 600.00sec in steps of 0.01sec
Voltage Response Side to Tie Point Switch ............... VS/VL/VS&VL
Tie Point Switch Operation Count ............................ 1 ~ 5 Shot in steps of 1 Shot
Tie Point Switch Close Operation Time Delay ......... 0.00 to 600.00sec in steps of 0.01sec
Tie Point Switch Open Operation Time Delay .......... 0.00 to 600.00sec in steps of 0.01sec
Tie Point Switch Reset Time Delay ........................... 1.00 to 600.00sec in steps of 0.01sec
Dead Line Time Delay of Source Side ...................... 0.00 to 600.00sec in steps of 0.01sec
Dead Line Time Delay of Load Side ......................... 0.00 to 600.00sec in steps of 0.01sec
Level Accuracy .......................................................... ± 5%
Timing Accuracy ....................................................... ± 5% of setting time or ± 20msec
