Multi-Function Control ETMFC610 http://www.entecene.co.kr
Trigger Capacity
Maximum 32 events are recorded.
Recorder Cycle Length
60 cycles for 64 sampling, 120 cycles for 32 sampling and 240 cycles for 16 sampling.
9.4. System Event
Maximum 5,000 events are recorded.
Move to “MAIN MENU / EVENT / SYSTEM” to confirm system events.
No. 0001/5000
ITEM : CPULINK
STATUS : HI/ASSERT
2018/01/01 00:00:00
No. 0002/5000
ITEM : CLST
STATUS : LO/DEASSERT
2018/01/01 00:01:00
[▼][▲] button is used to check the records. [0001/5000] is the latest event record.
Trigger Source
Protection element
52A Contact
Sequence status
Front panel control
AC supply
External control
Fail operation
External input status
System alarm
Sleep mode
Gas Status, etc.
Trigger Time
Monitors changes of Trigger source status in every 1/4 cycle.
