Multi-Function Control ETMFC610 http://www.entecene.co.kr
9.6.2. Load & Energy/Hour Event
Peak load & Energy event is recorded in every hour. Maximum load in every hour, is recorded up
to 8,640 events, it’s about 360 days events are recorded.
Move to “MAIN MENU / EVENT / LOAD&ENERGY/HOUR” to confirm Peak Load &
Energy/Hour events.
*. NOTE ) Configuration display for peak. load/min events may be revised on user’s request.
[▼][▲] button is used to check the events. To check real active power and reactive power, press
[ENT] button in Current display screen. To return back to current display screen, press [ENT]
again. [0001/8640] is the latest event record.
Trigger Source
Demand Current – A, B, C, G
Demand Voltage – A, B, C, R, S, T
Demand Active Power - A, B, C, 3ф
Demand Reactive Power – A, B, C, 3ф
Demand Power Factor – A, B, C, 3ф
Demand Energy - Positive Watthour(3ф), Positive Varhour(3ф)
Trigger Time
Monitors changes of Trigger source status in every 1hour.
