7.2.2. Port Setup
Place the curser on “PORT SETUP” in COMMUNICATIN menu, press [ENT] button to move into
this menu. ETMFC610 communication port and related elements are set in this menu and it has
sub-menu as below.
7.2.2.1. RS232-1 and RS232-2 Ports Setup
ETMFC610 side panel RS232-1 and RS232-2 ports and related elements are set.
Move to “MAIN MENU/ GLOBAL SETTING/ COMMUNICATION/ PORTS/ RS232-1” to
select setting for RS232-1 port. Also, settings for RS232-2 port are same as below.
GLOBAL SETTING/ COMMUNICATION/ PORTS/ RS232-1/ Baud Rate
Range
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Default
9600
Step
~
Select the baud rate for RS232-1 port.
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ Parity Bit
Range
NONE, ODD, EVEN
Default
NONE
Step
~
Select whether to use Parity Bit.
[PORT SETUP]
>1.RS232-1
2.RS232-2
3.RS485
4.ETHERNET
[RS232
-
1]
>Baud Rate: 9600
Parity Bit: NONE
Data Bit: 8
Stop Bit: 1
Modem Sel: 4W
[1200 ~ 115200 bps]
[RS232
-
1]
>Baud Rate: 9600
>Parity Bit: NONE
Data Bit: 8
Stop Bit: 1
Modem Sel: 4W
[NONE/ODD/EVEN]
