Multi-Function Control ETMFC610 http://www.entecene.co.kr
13. METERING
Place the curser on “METERING” in Main menu, press [ENT] button to move in this menu. This
menu has sub-menu as below. Press [ENT] to move into sub-menu.
The accuracy of the measurement value displayed in this menu is “2.3. Metering Accuracy”.
13.1. Current
Following values are contained in the current metering.
R.M.S CURRENT
IA : Displays the measured phase A RMS current and phasor (A, deg°)
IB : Displays the measured phase B RMS current and phasor (A, deg°)
IC : Displays the measured phase C RMS current and phasor (A, deg°)
IG : Displays the measured ground RMS current and phasor (A, deg°)
SEF: Displays the measured sensitive earth RMS current and phasor (A, deg°)
SEQUENCE CURRENT
I1 : Displays the measured normal voltage and phasor.(A, deg°)
I2: Displays the measured negative phase sequence current and phasor. (A, deg°)
3I0: Displays the zero sequence current and phasor. (A, deg°)
PEAK CURRENT
Peak IA : Displays the measured phase A Peak current (A)
Peak IB : Displays the measured phase B Peak current (A)
Peak IC : Displays the measured phase C Peak current (A)
Peak IG : Displays the measured ground Peak current (A)
Peak IQ : Displays the measured negative sequence Peak current (A)
>1.CURRENT
2.VOLTAGE
3.FREQUENCY
4.POWER
5.ENERGY
6.DEMAND
7.UNBALANCE
8.HARMONICS
9.TRUE R.M.S
10.TD
11.CONTROLLER REF
