2.4. Fault Indication Type Functions
Fault Indication
Phase/Ground/Negative Sequence Pickup Level ...... OFF, 10 to 1600A in steps of 1A
Sensitive Earth Fault Pickup Level ........................... OFF, 0.1 to 160.0A in steps of 0.1A
*. The setting range of Pickup Level can vary
according to H/W option.
Permanent/Temporary FI Time.................................. 1 to 180 sec in steps of 1 sec
Type I Delay Time ..................................................... 0.01 to 180.00 sec in steps of 0.01 sec
Dropout Level ........................................................... 96 to 98% of Pickup
Pickup Level Accuracy .............................................. ± 5% of setting time or ± 20㎳
Inrush Duration Time
Phase/Ground/S.E.F/NEQ Inrush Duration Time ..... 0.00 to 600.00sec in steps of 0.01 sec
Make Use ‘I’ .............................................................. NO/YES
Timing Accuracy ....................................................... ± 5% of setting time or ± 20㎳
Fault Indication Auto Reset
Auto Reset Mode ....................................................... OFF/Temporary/Permanent/ALL
Auto Reset Time ........................................................ 0.01 to 600.00sec in steps of 0.01 sec
Timing Accuracy ....................................................... ± 5% of setting time or ± 20㎳
