16.2. COMTRADE
ETR-300R supports COMTRADE(Common Format for Transient Data Exchange) format files of
fault waveforms recorded on fault event log. After executing FTP utility, enter IP address of
ETMFC610 required to patch firmware and No.21 for the number of ports on TLS settings of FTP
utility. Password refers to 'User 1 PW' setting on “GLOBAL SETTING / COMMUNICATION /
FTP-SSL / User1 PW”. Access “/home/ entec_user/COMTRADE” on the FTP utility.
16.2.1. File format and Name
ETMFC610 generates binary type COMTRADE files, only. Example of generated COMTRADE
file name are 'W2C_##.CFG' and 'W2C_##.DAT'’ Here, ## is the order in which they are
generated.
16.2.2. Related Setting Items
COMTRADE file relates following settings;
Table 16-1. Setting Items
Menu Location Description
GLOBAL SETTING >> GENERAL >>
EVENT RECORDER >> COMTRADE Record
COMTRADE file is generated or not (ON/OFF)
GLOBAL SETTING >> GENERAL >>
EVENT RECORDER >> COMTRADE Rev.
Select COMTRADE standard's revision version which
be applied (1999/2013)
GLOBAL SETTING >> GENERAL >>
EVENT RECORDER >> COMTRADE P/S
Select Analog channel wanted to generate
COMTRADE file (Primary :1st, Secondary: 2
nd
)
GLOBAL SETTING >> GENERAL >>
EVENT RECORDER >> COMTRADE Rate
Enter the rate of COMTRADE waveform wanted to
generate(1~10:1)
