2. TECHNICAL SPECIFICATIONS
2.1. Inputs and Outputs
SYSTEMS
 3phase-3wire or 3phase-4wire, 38㎸ maximum, 800 Amp maximum
FREQUENCY
 50 / 60㎐ system and ABC/ACB phase rotation
CONTROL VOLTAGE INPUT
 AC Voltage Input 24Vac (±20%)
 Nominal Battery Voltage : 24Vdc
 Power Consumption : 8.4W at 24V dc
USER AVAILABLE DC POWER OUTPUT
 DC Power Voltage : 24Vdc or (12Vdc, 15Vdc option)
 DC Power Continuous : 40W(60W/1 min)
VOLTAGE TRANSFORMER INPUTS (VT)
 Voltage Inputs Va, Vb, Vc, Vr, Vs, Vt(
 Input Voltage Range : Phase-Neutral Continuous <8V
 Burden: 0.002VA(4V)
VOLTAGE TRANSFORMER INPUTS (VT) - Option
 Voltage Inputs Va, Vb, Vc, Vr, Vs, Vt
 Input Voltage Range : Phase-Neutral Continuous <300V
 Burden: 0.6VA(300V), 0.2VA(220V), 0.05VA(120V), 0.02VA(67V)
