Multi-Function Control ETMFC610 http://www.entecene.co.kr
LAMP TEST / FI RESET
Fault indication and fault target status are reset.
And all LED lamps on the user interface panel are test (All lamps are ON for a while).
AUX 1
Depending on user’s request, manufacturer sets a function on the LED. When the LED is on, the
function is operated.
6.1.3. Menu Control Section
ETMFC610 has 20
8 LCD (Liquid Cristal Display) display.
LCD DISPLAY
8x20 Characters display
CONTROL KEYS
[▲] [▼] [◀] [▶]
Arrow keys are used for the moving between the menu window and the changing of the setting
value
[▲] (METER) : Up arrow key is used to move to the meter menu, operable in menu starting mode
[▼] (AWAKE) : Down arrow key is used for panel awake from sleep mode
[◀] (EVENT) : Left arrow key is used to move to the event menu, operable in menu starting mode
[▶] (SET) : Right arrow key is used to move to the setting menu, operable in menu starting mode
[FUN] : To move to main menu when present mode is in starting mode
[ESC] : To cancel for data input mode or return the display to the previous level
[ENT] : To select sub menu or data input
NOTE
If control panel is awaken from sleep mode using [AWAKE] key, it must be set to
“KEY”
or
“BOTH”
in setting menu
“MAIN MENU / GLOBAL SETTING / GENERAL / DEVICE /
PANEL SLEEP / Awake Method”
.
To Next Page
