13.3. Frequency
Following values are contained in the frequency metering.
 Source: Metering value of present source side frequency is indicated.
 Load : Metering value of present load side frequency is indicated.
 Slip : Frequency difference between the power source side and the load side is indicated.
You can confirm in “MAIN NEMU / METERING / FREQUENCY”
MAIN MENU / METERING / FREQUENCY
Frequency Display
 Source
- Frequency in source side (Hz)
- Frequency decay rate in source side (Hz/sec)
 Load
- Frequency in load side (Hz)
- Frequency decay rate in load side (Hz/sec)
 Slip
- Frequency difference between source and load sides: Slip
frequency (Hz)
- Phase difference between sour and load sides : Slip angle (deg°)
[
FREQUENCY
]
Source: 0.00 Hz
0.00 Hz/s
Load : 0.00 Hz
0.00 Hz/s
Slip : 0.00 Hz
0.00 D
