GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ Data Bit
Range
7, 8
Default
8
Step
1
Select the Data Bit.
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ Stop Bit
Range
1, 2
Default
1
Step
1
Select the Stop Bit.
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ Modem Sel
Range
2W, 4W, DIAL, NONE
Default
4W
Step
~
Select a modem for communication.
 2W : 2 wire private line is used and continuously Carrier is
monitored to control data flow by DCD(Data Carrier Detect).
 4W : 4 wire private line is used and RTS(Request To Send) and
CTS(clear to Send) signal are used to control data flow.
 DIAL : Dial-Up1 modem is used.
 NONE : Not used.
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ CTS Usage
Range
DISABLE, ENABLE
Default
ENABLE
Step
~
Select whether to use CTS signal or not.
 ENABLE : Data is transferred after confirming CTS signal is
Asserted.
 DISABLE : Data is transferred regardless of CTS signal.
[RS232
-
1]
>Baud Rate: 9600
Parity Bit: NONE
>Data Bit: 8
Stop Bit: 1
Modem Sel: 4W
[7~8:1]
[RS232
-
1]
>Baud Rate: 9600
Parity Bit: NONE
Data Bit: 8
>Stop Bit: 1
Modem Sel: 4W
[1~2:1]
[RS232
-
1]
>Baud Rate: 9600
Parity Bit: NONE
Data Bit: 8
>Stop Bit: 1
>Modem Sel: 4W
[2W/4W/DIAL/NONE]
[RS232
-
1]
>CTS Usage: ENABLE
>DCD Usage: DISABLE
>RTS Usage: AUTO
>CTS CheckOut: 2
>DCD CheckOut: 5000
[DISABLE/ENABLE]
