GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ DCD Usage
Range
DISABLE, ENABLE
Default
DISABLE
Step
~
Set whether to use DCD signal.
 ENABLE : Data is transferred after confirming DCD signal is
Deasserted.
 DISABLE : Data is transferred regardless of DCD signal
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ RTS Usage
Range
OFF, ON, AUTO
Default
AUTO
Step
~
 ON : RTS signal of ETMFC610 is always ON(Assert).
 OFF : RTS signal of ETMFC610 is always OFF(Deassert).
 AUTO : On requesting data transfer to Modem, after RTS signal of
ETMFC610 is on and after data transfer completion, RTS signal of
ETMFC610 is off.
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ CTS CheckOut
Range
1 ~ 255 sec
Default
2
Step
1 sec
Set a waiting time that waits Modems confirmation on RTS signal
which informs that ETMFC610 is ready to transfer a data. If there is no
CTS response within a set time, RTU confirms CTS Fail and does not
transfer the data.
It is available if ‘CTS Usage’ setting is ON.
GLOBAL SETTING/ COMMUNICATION/ PORTS / RS232-1/ DCD BackOffDly
Range
10 ~ 30000 msec
Default
5000
Step
10 msec
Set a delay time of DCD signal checks which determine modem status
before sending RTS signal in 2 wire communication type. After a set
time, if DCD signal is ON, ETMFC610 does not transfer the data and
treat it as DCD Fail. It is available if ‘DCD Usage’ setting is ON.
[RS232
-
1]
>CTS Usage: ENABLE
>DCD Usage: DISABLE
>RTS Usage: AUTO
>CTS CheckOut: 2
>DCD CheckOut: 5000
[DISABLE/ENABLE]
[RS232
-
1]
>CTS Usage: ENABLE
>DCD Usage: DISABLE
>RTS Usage: AUTO
>CTS CheckOut: 2
>DCD CheckOut: 5000
[OFF/ON/AUTO]
[RS232
-
1]
>CTS Usage: ENABLE
>DCD Usage: DISABLE
>RTS Usage: AUTO
>CTS CheckOut: 2
>DCD CheckOut: 5000
[1~255:1s]
[RS232
-
1]
>CTS Usage: ENABLE
>DCD Usage: DISABLE
>RTS Usage: AUTO
>CTS CheckOut: 2
>DCD BackOffDly:5000
[10~30000:10ms]
