Multi-Function Control ETMFC610 http://www.entecene.co.kr
LCD Initial Screen
Press [ENT] button to check operation status on the Initial Screen to see loop control mode.
Table 7-3. Initial Screen for Loop Control
INITIAL SCREEN
ⓐ Loop Control function are as below.
OFF : Loop Control function does not operate.
SEC : It operates as Auto Sectionalizer.
TIE : It operates as Tiepoint Switch.
OPERATE ST: Displays the present operating status.
RESET : Reset status
RUNNING : Operation counter is increasing.
LOCKOUT : When at “SEC”, it displays. When operation coutner is up to
maximum setting, recloesr will be at open operating.
CLOSING : When at “TIE”, it is standby status for close operation order.
OPENING : When at “TIE”, it is standby status for opening operation
order
52 CONTACT: It displays the status of Switch main contact
CLOSE: Displays main contact is closed.
OPEN: Displays main contact is opened.
TROUBLE: It is displayed in case of Contact status is incorrect or cable
connection is not completed.
SOURCE VOLT: Displays the status of of source side voltage(LIVE or
DEAD LINE)
LOAD VOLT: Displays the status of load side voltage(LIVE or DEAD LINE)
O-COUNT SET : Displays the set operate count
O-COUNT NO. : Displays the present operate count
LOOP CONTROL <
ⓐ
>
OPERATE ST [ RESET]
52A CONTACT[ CLOSE]
SOURCE VOLT[ LIVE-L]
LOAD VOLT[ LIVE-L]
O-COUNT SET[ 4]
O-COUNT NO.[ 0]
OPERATE ST [ RESET]
52A CONTACT[ CLOSE]
SOURCE VOLT[ LIVE-L]
LOAD VOLT[ LIVE-L]
O-COUNT SET[ 4]
O-COUNT NO.[ 0]
