Multi-Function Control ETMFC610 http://www.entecene.co.kr
METERING
Each Phase Current and Phasor : Ia, Ib, Ic, Ig, Isef
Each Phase Pick Current : Ia, Ib, Ic, Ig, Iq
Each Phase and Line to Line Voltage and Angle : Va, Vb, Vc, Vr, Vs, Vt, Vab, Vbc, Vca, Vrs,
Vst, Vtr
Current and Voltage Symmetrical Component : I1, I2, 3I0, V1, V2, 3V0
Source and Load side Frequency, Frequency Change Rate, Slip Frequency and Slip Angle
Single Phase and Three Phase Power : Active Power(kW), Reactive Power(kVar), Apparent
Power(kVA), Power Factor(%)
Positive and Negative Energy : Active Energy(kWh), Reactive Energy(kVarh)
Present and Positive/Negative Maximum Demand
- Demand Current : Ia, Ib, Ic, In, Iq
- Single Phase and Three Phase Active Power(kW) and Reactive Power(kVar)
Source/Load side Voltage and Current Unbalance
Voltage and Current Harmonics (THD, 2nd ~ 31th order)
Voltage and Current True R.M.S
ETMFC610 Condition Reference
- Battery Voltage, Charger Voltage and Charger Current
- Battery Capacity
- ETMFC610 Internal Temperature
- ETMFC610 External Temperature
- System Power : +12V, -12V, Reference Voltage
COMMUNICATIONS
Side panel RS232-1 and RS232-2 Serial Port : DNP 3.0, Modbus, IEC60870-5-101 and Multi-
Bit Protocol, ETMFC610 Interface Software
Side panel RS485 Port : DNP 3.0, Modbus, IEC60870-5-101 and Multi-Bit Protocol
Side panel Eth1 and Eth2 Ethernet Port or Fiber Optic(Option) Port : DNP 3.0, Modbus,
IEC61850(option), IEC60870-5-104 and Multi-Bit Protocol, ETMFC610 Interface Software
Front Panel USB-B Type Port : ETMFC610 Interface Software
