Hang up
 DTR Line is deasserted
 Wait 2 second
 DTR Line is asserted
 Wait 2 second
※ . ETMFC610 will hang up the modem after a delay of 30 seconds with no valid packet received
or transmitted.
7.2.3.3. Dialup Modem Setup
Place the curser on “DIALUP MODEM” in COMMUNICATION menu, press [ENT] button to
move into this menu.
The settings for the dialup modem are shown below;
1) Calling String
In order to set “Calling String”, move to “MAIN MENU/ GLOBAL SETTING/
COMMUNICATION/ DIALUP MODEM/ DIALUP MODEM 1/ CALLING STRING”
GLOBAL SETTING/ COMMUNICATION/ DIALUP MODEM/ CALLING STRING
Range
ATD, ATDT, ATDP
Default
ATD
Step
~
Set to use Dial-Up modem use. Select a dial string one among them.
 ATD : Default Dial Type(Already set in modem(Default Dial type)
 ATDT : Tone Dial
 ATDP : Pulse Dial
[CALLING STRING]
>CS: ATD
[! ~ z]
[DIALUP
MODEM
]
>1.DIALUP MODEM 1
2.DIALUP MODEM 2
[DIALUP
MODEM 1
]
>1.CALLING STRING
2.CALLING NUMBER
3.INITIAL STRING
4.CONNECTION
