The underfrequency element should be enabled to following settings.
1) UNDER FREQUENCY 1 Setup
The under frequency 1 should be enabled to following settings.
GROUP # / MONITORING / FREQUENCY / UNDER FREQUENCY1 / Function
Range
DISABLE, ENABLE
Default
DISABLE
Step
~
Set the function of under frequency 1 element as enable or disable.
If function = DISABLE, the feature is not operational.
If function = ENABLE, the feature is operational. When the feature
asserts an alarm condition, the device gives the alarm.
GROUP # / MONITORING / FREQUENCY /UNDER FREQUENCY1 / Pickup
Range
40.00 ~ 65.00 Hz
Default
58.50
Step
0.01Hz
Enter the level of which the underfrequency element is to pickup.
GROUP # / MONITORING / FREQUENCY /UNDER FREQUENCY1 / Time Delay
Range
0.00 ~ 600.00 sec
Default
2.00
Step
0.01 sec
It sets the delay time to operate the underfrequency element.
GROUP # / MONITORING / FREQUENCY / UNDER FREQUENCY1 / Reset Time
Range
0.00 ~ 600.00 sec
Default
2.00
Step
0.01 sec
It sets the time to reset the underfrequency element
[UNDER FREQUENCY1
]
>Function: DISABLE
Pickup: 58.50
Time Delay: 2.00
Reset Time: 2.00
Min.Volt: 0.10
[DISABLE/ENABLE]
[UNDER FREQUENCY1
]
Function: DISABLE
>Pickup: 58.50
Time Delay: 2.00
Reset Time: 2.00
Min.Volt: 0.10
[40.00~65.00:0.01Hz]
[UNDER FREQUENCY1
]
Function: DISABLE
Pickup: 58.50
>Time Delay: 2.00
Reset Time: 2.00
Min.Volt: 0.10
[0.00~600.00:0.01s]
[UNDER
FREQUENCY1
]
Function: DISABLE
Pickup: 58.50
Time Delay: 2.00
>Reset Time: 2.00
Min.Volt: 0.10
[0.00~600.00:0.01s]
